Engineering & DesignFrom sketch to shop floor.
CAD development and buildability review that takes your concept from sketch to production-ready drawings before any metal is cut.
WHAT IS IT
Not every job arrives as a finished drawing. Our engineering team takes a sketch, a sample, or a rough concept and turns it into CAD the floor can actually build.
Because design and fabrication share one building, bend allowances, weld access, and material choice get settled on screen before any metal is cut.
When you need it
Bring us a napkin sketch when the part still needs inventing, or a finished drawing that needs a buildability pass before it hits the floor.
Every approved design hands off straight into shearing, laser, punch, form, or weld. Nothing is lost between offices.
How it works
From concept to a fabricatable file
1 · CONCEPT
Talk through the part
We start with function, environment, and budget: what the part must do, where it lives, and what it has to survive.
CONSULT · SCOPE · CONSTRAINTS
Design path
Decide how you want to start
Start with us
- Ideal when the design still needs to be worked out
- Sketch, sample, or rough concept is enough
- Buildability built in from the first model
- One team from concept through fabricated part
You already have CAD
- We review for cost, tolerance, and fab practicality
- Flag issues at quote time, not after parts are cut
- Supply STEP, DXF, or DWG in the format you use
- Still routes straight into our shop floor
Tradeoffs
Advantages & considerations
Advantages
Considerations
Start a job
How to order
1
Share Your Idea
Send a sketch, sample part, or rough concept. Any starting point works.
2
Design Consultation
We talk through function, materials, and budget with our engineering team.
3
CAD Development & Review
We model the part and review drafts with you until the design is approved.
4
Handoff to Fabrication
The approved design moves straight to our shop floor for production.
5
Deliver on Time
Quality checked and shipped when promised, with your schedule treated as part of the design.
Other Services
Related Services
Need a design
consultation?
Send a sketch, sample, or rough concept. We will tell you what the shop can hold.
